A Growth-Enhancing Pest Management Option

Tacy CalliesHLB Management, Research

Particle films
Red-dyed kaolin reduces the ultraviolet and blue light that Asian citrus psyllids are attracted to.

By Christopher Vincent

Particle films can both increase tree growth and reduce Asian citrus psyllid populations. University of Florida (UF) research has found particle films delay infection with the CLas bacterium, which causes HLB. They also enhance growth rates and yield. Particle films do have limitations to efficacy, including being washed off in frequent or heavy rains. Overall, particle films offer an important pesticide alternative, which growers should consider integrating into their production practices.

Particle films are solid particles that can be sprayed in a water suspension onto plants to form a coating over leaf surfaces. These films are commonly used in horticultural crops to manage insect pests, reduce sunburn or enhance growth. People often ask me whether the film plugs up the plant’s pores. It turns out that they do not. Rather, the particles sit around the pores (stomata) reflecting light in different directions. Particle films do not keep gases from moving in an out of the leaf. This is important because it means they do not prevent the plant from photosynthesizing or from cooling itself.

An ongoing trial was treated beginning on the first day of the planting with either no foliar insecticides, foliar insecticides, white kaolin or red-dyed kaolin. The white kaolin is Surround WP, a commercially available particle film. Red kaolin is not yet commercially available. Treatments are made whenever rain washes the kaolin product off, which has been every two weeks on average over the first two years of the planting.

HOW EFFECTIVE ARE PARTICLE FILMS AGAINST PSYLLIDS?
Particle films reduce Asian citrus psyllid (ACP) populations by reflecting light. The film covers up the natural color of the leaves that attracts the insects. The red dye gives an additional boost by reducing ultraviolet and blue light that also attract ACP. The insects are not attracted to red. Both red and white kaolin have greatly reduced ACP populations, by more than 80 percent compared to the insecticide control. The insecticide control only reduced ACP by about 20 percent relative to the untreated control over the course of the year, though it did reduce peak populations by about half.

The reduction in ACP that insecticides caused was not enough to delay infection with CLas, but particle films did delay infection. Two years after planting, both treatments with no particle films are very close to 100 percent infected. The two treatments with particle films are approximately 60 percent infected. Infection in the red-dyed treatment was not detected until more than one year after planting. Some infections were found in the other treatments by six months after planting.

Particle films
Kaolin applied to citrus can delay HLB infection.

HOW DO PARTICLE FILMS AFFECT GROWTH?
Growth results have been overwhelmingly positive. The white particle film increased growth by 20 percent, while red film saw a 40 percent increase. At 17 months after planting, fruit was harvested from treated Hamlin trees. Though the quantity of fruit was small, the treatments without particle film produced almost no fruit. Higher yields in the first complete season indicate much better growth status in the particle film treatments. Much higher yields are expected in the coming season.

What causes the increased growth? Delaying infection with CLas is certainly helping the trees in the trial, but particle films increase growth even when not considering the effects of HLB. So far, the effects on growth rate hold for both infected and uninfected trees. This has to do with the fact that full sunlight is too much for a citrus leaf. The leaves on the outside of the canopy are overwhelmed by so much light that they must expend energy to protect themselves from the damage caused by the light. This is seen in leaf temperature measurements. On summer days, citrus leaves in full sun reach nearly 120 degrees in the afternoon, but particle films reduce the afternoon leaf temperature to about 104 degrees.

At the same time, without particle films, leaves deeper in the canopy are often shaded too much and are not able to photosynthesize at their full potential. Particle films help the tree by reflecting the light in different directions. This means that the films shade the outer leaves, reflecting the light away. Some of that reflected light is directed into the rest of the canopy, giving the inner leaves greater light. This leads to a light distribution that is closer to optimum for the whole tree canopy.

WHAT ARE THE LIMITATIONS OF PARTICLE FILMS?
Particle films have several limitations for use in the field. The red particle film is currently not a registered commercial product, but there are several white kaolin products available. Only Surround WP is labeled for pest management in citrus. The biggest challenge with using particle films is that frequent rains wash the particles off. Thus, particle films can require frequent reapplication depending on rainfall. In the UF field study, reapplications have been made every two weeks, on average. Frequent application drives up the cost of using particle films.

Although small amounts of flush do not appear to interrupt the effects of particle films on ACP, a major flush, especially in young trees, can cover up a particle film underneath the new foliage. The particle film can only have its intended effect if it is on the outside of the canopy. Ironically, in the UF study, the increased growth of the particle film treatments caused larger spring flushes. For this reason, insecticidal options may provide better pest management during major flushes.

Particle films also do not affect all important citrus pests. For example, no effects of particle films on citrus leafminers have been found. Although mite problems have not been found in the UF field trial, other researchers have observed spider mite outbreaks in particle-film-treated plants.

CONCLUSIONS
Particle films can be an effective pest management tool and a valuable growth enhancer. In the HLB era, both benefits are important. Delaying infection and reducing ACP feeding increases the likelihood that a new planting will reach a productive state. Increasing the growth rate means that the plants will become more productive. Of course, every approach has its cost, and need for frequent reapplication increases the cost of particle films. Growers should weigh the costs versus the benefits when considering whether to include particle films in their production systems.

Christopher Vincent is an assistant professor at the University of Florida/Institute of Food and Agricultural Sciences Citrus Research and Education Center in Lake Alfred.
